Applications of HDPE Composite Aluminum Composite Panels

Applications of HDPE Composite Aluminum Composite Panels

HDPE composite aluminum composite panels have a wide range of applications, thanks to their unique properties, offering advantages over other materials in various fields. HDPE composite aluminum composite panels retain the main characteristics of their original constituent materials (metallic aluminum and non-metallic polyethylene plastic) while overcoming their shortcomings, resulting in numerous superior material properties such as luxurious appearance, vibrant colors, weather resistance, corrosion resistance, impact resistance, fire resistance, moisture resistance, sound insulation, heat insulation, and shock resistance; lightweight, easy processing and molding, and easy handling and installation. Therefore, they are widely used in various building decorations, such as ceilings, column cladding, counters, furniture, telephone booths, elevators, shop fronts, billboards, and factory wall materials. They have become a representative of metal curtain walls (one of the three major curtain wall types, natural stone, glass, and metal). In developed countries, composite aluminum composite panels are also used in the manufacture of buses and train carriages, as sound insulation materials for aircraft and ships, and in the design of instrument enclosures.


Composition of HDPE Composite Aluminum Composite Panel machine

序号NO. 设备Equipment 수량 수량
1 85/170 同向锥双挤出机95/203 Co-rotating conical screw 1개 단위 1 세트
2 模具及液压换网器T-die and Hydraulic screen changer 1세트 1세트
3 1950mm宽PE板机头1950mm T-die for 1700mm PE sheet 1세트 1세트
4 JWLY2000三辊压光机JWLY 2000 Two-roller calendar 1세트 1세트
5 水介质辊筒恒温装置Water medium calendar temperature controller 1세트 1세트
6 覆高分子粘结膜机Macromolecule film covering unit 1개 단위 1 세트
7 四工位上下放铝箔机Four-station aluminum-placing unit 1개 단위 1 세트
8 铝塑热复合机Thermo-shaping machine for plastic-aluminum plate 1개 단위 1 세트
9 冷却装置Cooling Unit 1세트 1세트
10 冷却风箱Cooling unit 1세트 1세트
11 覆保护膜机Protection film covering unit 1개 단위 1 세트
12 牵引机Haul-off unit 1개 단위 1 세트
13 滚切,修边机组Generating cutting trimming machine 1개 단위 1 세트
14 横切、输送机Transverse cutter and transmission machine 1개 단위 1 세트
15 高温导热油加热器High temperature conductive oil 1개 단위 1 세트
16 五辊校平装置Five Roller leveler 1개 단위 1 세트
17 机械手Automatic stacker 1개 단위 1 세트
18 2000Kg/h 上料机(磁力架)2000kg/h Auto loader (magnetic rack) 1개 단위 1 세트
19 PLC控制系统PLC control unit 1세트 1세트
